The ACTE POXA1328-007 ultra-compact GPS module uses the POT (Patch On Top) format to keep the size down to only 16 x 16 x 6.2mm and the MediaTek MT3339 chipset for -165dBm sensitivity. It features lightning fast time to first fix (TTFF) whilst keeping power consumption down to 82mW during acquisition and 66mW while tracking. The module supports up to 210 x PRN (Pseudo Random Noise) channels, 66 x search channels and 22 x simultaneous tracking channels. Its repertoire of location and navigation applications includes autonomous GPS, SBAS ranging (WAAS, EGNO, GAGAN, MSAS), and AGPS.
- Ultra-High Sensitivity: -165dBm (w/o patch antenna)
- Up to 10Hz update rate
- 12 x multi-tone active interference canceller
- High accuracy 1-PPS timing output for timing applications (10ns jitter)
- AGPS Support for Fast TTFF (EPO™ Enable 7 days/14 days/30 days)
- Self-Generated Orbit Prediction for instant positioning fix
- Intelligent Advanced Power Periodic Mode algorithm for power saving
- Logger function Embedded
- Typical current consumption(@3.3V): acquisition 25mA, tracking 20mA
- Certification: E911, RoHS, REACH compliant, CE, FCC
| Input Voltage |
3.0 to 4.3V |
| Max. Update Rate |
10S/s |
| Position Accuracy |
3m |
| Sensitivity |
165dBm |
