Epcos B72220P3351K101 350V 335J 20mm Metal Oxide Leaded Varistor

A Ø20mm metal oxide disk varistor with an operating voltage of 350V AC. The device is a voltage-dependent resistor whose resistance decreases as voltage increases. When connected in parallel with the component or circuit requiring protection the varistor forms a low-resistance shunt, preventing any rise in surge overvoltage. The varistor is a proven protective device due to its application flexibility and high reliability.

• Clamp voltage 910V @ I_C 100A
• Optimum overvoltage and transient suppression protection
• High resistance at low voltages and low resistance at high voltages
• Tolerance 10%
• Radial leaded
• Epoxy resin coated
• Multiple pulse handling capability
• Also known as Transient Voltage Surge Suppressors (TVSS)
• UL, CSA, VDE, IEC approved
