Hongfa HF14FW/012-HSPTF PCB Relay 12VDC SPST-NO 20A

Hongfa
Standard range
Order Code:

71-4654

Brand: Hongfa MPN: HF14FW/012-HSPTF
Qty Was Unit Price (Ex VAT)
1+ £0.558   £0.521
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
193 in stock, despatched same dayContact us for additional stock

A 20A miniature high power relay from the HF14FW series that is designed for PCB mounting. The relay has a 12V DC coil and a SPST-NO contact configuration.
  • Plastic sealed case
  • 4kV Dielectric strength
  • Class F insulation
  • 29.0 x 13.0 x 26.5
Coil Resistance 200Ω
Coil Voltage 12V
Contact Configuration SPST-NO
Height 26.5mm
Length 29.0mm
Mounting Type PCB
Operating Temperature -40 to +85°C
Switching Current 20A
Switching Power 5540VA
Switching Voltage Max (AC) 277V
Switching Voltage Max (DC) 30V
Type HF14FW
Width 13.0mm
