LappKabel 0048003 OLFLEX HEAT SIF Single Core Wire Silicon 1x0.5mm Brown

Standard range
Order Code:

52-1354

  Copy to clipboard
Brand: LappKabel  Copy to clipboard MPN: 0048003 Copy to clipboard
 Report an error
Qty Unit Price (Ex VAT)
10+ £0.294

Add to Quote

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Standard factory lead time 7 days
634 available to back orderBack-order availability date - 06/11/2024

The LappKabel 0048003 ÖLFLEX® HEAT SIF is a Single Core Wire that is ideal for Switchgear cabinet building, Appliances and apparatus engineering, Electric motor industry, Thermal and heating elements, Lighting technology, Ventilator engineering, Oven construction, Generator and transformer building.

The cable conductor has been manufactured from fine strands of tinned copper wires with a brown silicone based insulation.


  • Cable type: ÖLFLEX® HEAT 180 SiF
  • Cross-section: 1 x 0.5 mm²
  • Specific insulation resistance: >200GΩ x cm
  • Conductor stranding: Fine wire in accordance with VDE 0295, Class 5 /IEC 60228 Class 5 from 0.5 mm²
  • Rated voltage: U0/U 300/500V
  • Test voltage: 2000V
  • Operating temperature: -50°C up to +180°C
  • Outer diameter: 2.1mm
  • Copper index: 4.8kg/km
  • Supplied in brown
  • Supplied in lengths of 1m
  • Manufacturer's part: LappKabel 0048003

This cable will be supplied in one continuous length, subject to the maximum reel size. For example, an order for 7 metres of cable will result in a single 7-metre cable being supplied, not 7 one-metre lengths.
Conductor Stranding Fine wire in accordance with VDE 0295, class 5 / IEC 60228 class 5 from 0.5 mm²
Insulation Material N/A
Cable Diameter 2.1mm
Colour Brown
Conductor Cross-section 1 x 5mm²
Length Sold per metre
Sold by Metre Yes
Standards/Test Marks N/A
