Binder 09-9789-71-05 Male 5mm 5 Pin Cable Mnt Str Relief with Solder Terminal

Binder 09-9789-71-05 Male 5mm 5 Pin Cable Mnt Str Relief with Solder Terminal

Order Code:

55-1109

  Copy to clipboard
( Write a review )
Brand: Binder  Copy to clipboard MPN: 09-9789-71-05 Copy to clipboard
 Report an error

Discontinued

A male 5mm 5-pin black subminiature panel mount snap-in connector with strain relief and solder termination.
  • Number of poles: 5
  • Connector locking system: Snap-in locking
  • Termination: solder
  • Wire gauge (mm): 0,25 mm²
  • Wire gauge (AWG): 24
  • Cable outlet: max. 5 mm
  • Degree of protection: IP 40
  • Mechanical operation: >100 mating cycles
  • Upper temperature: +70 °C
  • Lower temperature: -25 °C
  • Rated voltage: 60 V
  • Rated impulse voltage: 800 V
  • Pollution degree: 1
  • Overvoltage category: II
  • Material group: III
  • Rated current (40°C): 3 A
  • Volume resistivity: ≤ 3 mΩ
  • Material of contact: CuZn (brass)
  • Contact plating: Au (gold)
  • Material of contact body: PA
  • Material of housing: PA
Contact Material Brass
Contact Plating Gold
Current Rating 3A
Gender Male
IP Rating IP40
Mounting Type Cable
Number of Ways 5
Termination Method Solder
Voltage Rating (AC) 60V
