Binder 99-2030-00-12 Female Cable Mount Miniature 12 Pin with 4-6mm Outlet

Binder 99-2030-00-12 Female Cable Mount Miniature 12 Pin with 4-6mm Outlet

Order Code:

55-0227

  Copy to clipboard
( Write a review )
Brand: Binder  Copy to clipboard MPN: 99-2030-00-12 Copy to clipboard EAN-13: 4016138137415
 Report an error

Discontinued

A 12-pin shieldable female M16 cable mount miniature connector with a 4 to 6mm outlet.
  • Number of poles: 12
  • Connector locking system: Screw
  • Termination: solder
  • Wire gauge (mm): 0,25 mm²
  • Wire gauge (AWG): 24
  • Cable outlet: 4 - 6 mm
  • Degree of protection: IP 40
  • Mechanical operation: >500 mating cycles
  • Upper temperature: +85 °C
  • Lower temperature: -40 °C
  • Rated voltage: 60 V
  • Rated impulse voltage: 500 V
  • Pollution degree: 1
  • Overvoltage category: I
  • Material group: III
  • Rated current (40°C): 3 A
  • Volume resistivity: ≤ 3 mΩ
  • Material of contact: CuSn (bronze)
  • Contact plating: Au (gold)
  • Material of contact body: PBT (UL 94 V-0)
  • Material of housing: CUZn (brass nickel plated)
Cable Diameter 4 to 6mm
Contact Material CuSn
Contact Plating Gold
Current Rating 3A
Gender Female
IP Rating IP40
Mounting Type Cable
Number of Ways 12
Termination Method Solder
Voltage Rating (AC) 60V
