Binder 99-5122-15-06 Female Cable Mount Silver Plated 6 Pin with 4-6mm Outlet

Name: Binder 99-5122-15-06 Female Cable Mount Silver Plated 6 Pin with 4-6mm Outlet
Brand: Binder
Price: 14.37 GBP
Availability: BackOrder

Standard range

Order Code:

55-0978

Brand: Binder MPN: 99-5122-15-06 EAN-13: 2050000420917

RoHS Compliant
Country of Origin:
Free UK shipping available
View Full Product Range (5)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£14.37

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

26 available to back orderBack-order availability date - 22/01/2025

Product Details
Data Sheets
Quick Quote

A silver plated 6-pin female DIN cable mount connector with a 4 to 6mm outlet.

Number of poles: 6
Connector locking system: Screw
Termination: solder
Wire gauge (mm): 0,75 mm²
Wire gauge (AWG): 20
Cable outlet: 4 - 6 mm
Degree of protection: IP 67
Mechanical operation: >500 mating cycles
Upper temperature: +95 °C
Lower temperature: -40 °C
Rated voltage: 250 V
Rated impulse voltage: 1500 V
Pollution degree: 1
Overvoltage category: I
Material group: III
Rated current (40°C): 5 A
Volume resistivity: ≤ 5 mΩ
Contact material: bronze
Contact plating: silver
Material of contact body: PBT (UL 94 V-0)
Material of housing: CUZn (brass nickel plated)

Cable Diameter	4 to 6mm
Contact Material	CuSn
Contact Plating	Silver
Current Rating	5A
Gender	Female
IP Rating	IP67
Mounting Type	Cable
Number of Ways	6
Termination Method	Solder
Voltage Rating (AC)	250V
